| Container Transport Semi-trailer | |
| Tare weight | 9000kg |
| Payload | 20000kg+40000kg |
| Overall length | 19450mm(6200mm+950mm+12300mm) |
| Overall width | 2500mm |
| Overall height | 3000mm |
| SPECIFICATION | |
| Chassis | Heavy duty and extra durability designed I beam; opting for high tensile steel, welded by
automatic submerged Arc processes. Top flange 12mm,width140mm;Middle Flange 6mm;bottom flange14mm, width 140mm |
| Axle | 5(2+3), FUWA,13T |
| Suspension | Mechanical suspension |
| Leaf spring | Leaf spring |
| Floor | 3mm side wall:2mm |
| Tire | 12.00R24 20pcs(8+12) |
| Wheel rim | 8.5-24 20pcs(8+12) |
| Kingpin | 2’’ bolt-in king pin |
| Landing gear | FUWA two-speed, manual operating ,heavy duty landing gear 28T |
| Twist lock | 16pcs of ISO twist locks for 1x20ft,2x20ft,1x40ft container |
| Vehicular applications | Cargo transport |
| Drawing | Including |
| Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| Painting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats
of final paint |
| Accessories | One standard tool box |
